FREEStyler 2 CtS system for imaging screen printing screens
Prices are only visible after registration.
ART-NR:
EX-FST2
Produktinformationen
The FREEStyler 2 from EXILE Technologies is a cost-effective, direct computer-to-screen system that prints digital images directly onto coated screens. With a robust industrial design and new algorithms for dot placement and bi-directional printing, it offers faster print speeds and improved image quality.
Technical specifications
- Model: FREEStyler 2 Computer to Screen System
- Printhead: Thermal drop-on-demand inkjet (1-4 offset printheads, software controlled)
- Resolution: 600x1200, 1200x1200 & 1200x2400 dpi
- Maximum screen size: 1050 mm high x 660 mm wide
- Ink type: Pigment-based, aqueous UV-blocking black ink
- UV blocking capability: UV density above 3.5
- Ink characteristics: Water soluble and non-hazardous
- Maximum image size: 735 mm high x 508 mm wide
- Imaging speed:
- Fast: 2.5 min per ft²
- Normal: 5 min per ft²
- HQ: 8 min per ft²
- Interface: USB (via PC Windows)
- Voltage: AC 120/220V auto-sensing
- Operating temperature: 10°C - 30°C
- Humidity: 40-70% relative humidity
- Weight: 50kg
- Dimensions: 1250 mm x 1020 mm x 420 mm
The FREEStyler 2 is equipped with CADLink's SCREENMAKER RIP, which enables easy creation of colour separations and includes a Windows print utility for maintenance and management. EX-FST2
